Capabilities
One Stop Shop
One Stop Shop
From concept to production volume : Busch Brothers has the capabilities, capacity & onsite talent to take your component from sketch to final part including post machining processing including heat treatment, anodizing, painting, powder coating, etc.
5 Axis
One Stop Shop
Busch Brothers Machining has invested in multiple 5 Axis machines to provide you with cutting edge capabilities. Our machine portfolio includes up to 500mm cubic capacity in all materials, including robotic loading for lights out production
- Doosan DVF 5000
- HAAS UMC 500SS
Swiss Machining
Swiss milling is a manufacturing technique that utilizes tool cutting designed to turn metal stock into complex, slender, or delicate components that require tight tolerances. Busch Brothers Machining utilizes four Citizen Swiss machines to produce a wide variety of high precision parts.
- Qty 3 - 32mm Citizen L32 Swiss Lathes with 12 ft bar feeds
- 20mm Citizen L20 Swiss Lathe with 12 foot bar feed
Horizontal Milling
Choosing the right machine for the job makes all the difference in the world in regards to precision, lead time and pricing. Busch brothers maintains a wide range of horizontal milling capabilities for your facing needs.
- Kitamura HX400 24x24x24" travel w/pallet shuttle
- Qty 2 - Makino A51 22x22x23.6" travel w/ pallet shuttle
Vertical Milling
Live tooling, pallet changers and articulating trunnions give our machinists greater capabilities to make your components in less time.
- Qty 3 - Haas VF-4SSAPC 50x20x25" Travel w/ pallet shuttle and indexing and 5 axis capabilities
- Qty 2 - Kitamura 2XI Sparkchanger
- Qy 2 - Mighty Comet VMC 1000
Conventional Lathe Machining
Busch Brothers offers one of the most versatile turning center portfolios in the region with Y axis, live tooling, and 3-12' bar feed capabilities.
- Nakamura WT300 Twin Spindle 23.8x43.3" capacity w/ live tooling & Fanuc robotic loading & unloading
- Mori Seiki F-LII 13.8x24" capacity
- Mori Seiki NLX2500 10" chuck 23.2"x27.7" capacity with Y axis live tooling
- Qty 2 - Doosan Puma GT 2600 14.8"x29" capacity
- Qty 2 - Doosan Lynx 220LMA with magazine bar feeders
Raw Material Logistics
Supply chain disruption and material scarcity have suddenly become the business norm. Busch Brothers maintains key relationships with raw material partners to ensure the material needed for your components is always available.
Customer Inventory & Kanban Services
Lean inventory and agile supply chains are key to your business success. Busch Brothers offers a full line of inventory management solutions including Kanban & Just In Time services.
Material Capabilities
Material Capabilities
Busch Brothers Machining maintains stock and machinist knowledge needed to process a wide variety of materials including -
- Stainless Steel
- Inconel
- Kovar F15
- Cold Rolled Steel
- Aluminum
- Brass
- Nylon
- Full range of plastics
- Tubing | Bar | Pipe | Hex | Plate
